AS3008 0.8VA Series

Power：0.8VA

Featrures

Product Parameter

PART NO	Primary [V]	No-Load Voltage [V]	Secondary [V/mA]	Pin	Schematic No.	Temperature Class	Certificates
							Certificates
							VDE	UL	CQC	CE
AS3008-E-0080-060-S	230	9.0	6/133	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-090-S	230	13.5	9/89	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-120-S	230	18.0	12/67	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-150-S	230	22.5	15/53	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-180-S	230	27.0	18/44	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-240-S	230	36.0	24/33	1+5/7+9	1	ta70℃/B				●
AS3008-E-0080-060-D	230	2x9.0	2x6/67	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-075-D	230	2x11.2	2x7.5/53	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-090-D	230	2x13.5	2x9/44	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-120-D	230	2x18.0	2x12/33	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-150-D	230	2x22.5	2x15/27	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-180-D	230	2x27.0	2x18/22	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-E-0080-240-D	230	2x36.0	2x24/17	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-060-S	115	9.0	6/133	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-090-S	115	13.5	9/89	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-120-S	115	18.0	12/67	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-150-S	115	22.5	15/53	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-180-S	115	27.0	18/44	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-240-S	115	36.0	24/33	1+5/7+9	1	ta70℃/B				●
AS3008-U-0080-060-D	115	2x9.0	2x6/67	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-075-D	115	2x11.2	2x7.5/53	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-090-D	115	2x13.5	2x9/44	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-120-D	115	2x18.0	2x12/33	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-150-D	115	2x22.5	2x15/27	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-180-D	115	2x27.0	2x18/22	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U-0080-240-D	115	2x36.0	2x24/17	1+5/6+7-9+10	2	ta70℃/B				●
AS3008-U2-0080-060-S	2x115	9.0	6/133	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-090-S	2x115	13.5	9/89	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-120-S	2x115	18.0	12/67	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-150-S	2x115	22.5	15/53	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-180-S	2x115	27.0	18/44	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-240-S	2x115	36.0	24/33	1+2-4+5/7+9	3	ta70℃/B				●
AS3008-U2-0080-060-D	2x115	2x9.0	2x6/67	1+2-4+5/6+7-9+10	4	ta70℃/B				●
AS3008-U2-0080-090-D	2x115	2x13.5	2x9/44	1+2-4+5/6+7-9+10	4	ta70℃/B				●
AS3008-U2-0080-120-D	2x115	2x18.0	2x12/33	1+2-4+5/6+7-9+10	4	ta70℃/B				●
AS3008-U2-0080-150-D	2x115	2x22.5	2x15/27	1+2-4+5/6+7-9+10	4	ta70℃/B				●
AS3008-U2-0080-180-D	2x115	2x27.0	2x18/22	1+2-4+5/6+7-9+10	4	ta70℃/B				●
AS3008-U2-0080-240-D	2x115	2x36.0	2x24/17	1+2-4+5/6+7-9+10	4	ta70℃/B				●
